The main focus is currently on the serious type of 7628, 2116, and 1080. In addition, it could be manufactured in accordance with customer’s demand.

SPECIFICATION：

Fabric Type Thread Count
(Warp Ends/ Inch)		 Thread Count
(Fill Ends/ Inch)		 Basic Weight
(g/m2)		 Width
(mm)		 Fabrics Roll Length
(M/Roll)		 Splices Width Of Edge
(mm)		 Width of Feather Edge
(mm)
7628 44±2 34±2 210±3 1275(+5、-2) 2900~3000 1↓ 4↓ 4↓
7667 44±2 36±2 235±3 1275(+5、-2) 2700~2900
7630 42±2 32±2 220±3 1276(+2、-2) 2700~2900
3313 60±2 62±2 81±2 1275(+2、-2) 1900~2200
2116 60±2 57±2 103±2 1275(+5、-2) 2900~3100
2313 60±2 64±2 81±3 1275(+2、-2) 1900~2200
2113 60±2 58±2 79±3 1275(+2、-2) 2000~2200
1086 60±2 58±2 52±1.4 1275(+5、-2) 1900~2200
1526 60±2 26±2 61±2 1100(+5、-0) 2000~2300
1080 60±2 47±2 47±2 1275(+5、-2) 2300~2700
1506 48±2 47±2 165±3 1275(+5、-2) 2800~3100
1078 54±2 54±2 48±2 1275(+5、-2) 1900~2200
106 56±2 56±2 24±1.5 1275(+5、-2) 1900~2100
1067 70±2 68±2 30±2 1275(+5、-2) 1900~2100
1035 66±2 68±2 29.5±1 1275(+5、-2) 1200~1500
1037 70±2 73±2 23±2 1275(+5、-2) 2000↑
1027 75±2 75±2 19.5±1 1275(+5、-2) 2000↑
1017 95±2 95±2 12.3±0.9 1275(+8、-0) 1200↑




To accommodate the constant variation and promote the product property in PCB market, Fulltech will stick to the principles of continually innovate, enthusiastically research and develop in order to enhance the competitive strength in the glass fabric industry.
The department of R&D is trying to increase the permeability and high temperature durability between the glass fabric and epoxy with its physical and chemical property. The research directions are as follows,
1. Physical approach- To flat yarn strand by a special Kaisen method which could make silane and epoxy
     fully impregnate.
2. Chemical approach- To increase the ability of combination between epoxy and glass fabric by
     improving the silane type.
3. Customized Approach: To make production based on clients` request of spec.
     and types of silane.
In addition, Fulltech will enthusiastically and continually have a research on special or thin fabric type to make Fulltech fabrics extensively applied in high-level products and HDI production process and also enhance the benefit.

This company had got the approval from the organization of TUV NORD with the version of ISO 9001:2015 in June, 2011.

This company had got the approval from the organization of TUV NORD with the version of 14001:2015 in March, 2012.

This company had got the approval from the organization of TUV NORD with the version of IATF 16949:2016 in December, 2019.
